Diamond Pro®

With greater square footage per unit than the popular  Diamond Pro® retaining wall is an ideal choice for large projects. Architects, engineers, and contractors choose Diamond Pro® to create flexible, cost-effective solutions for a broad range of large retaining wall projects.

Features & Benefits:

  • Rear-lip locator.
  • Large cores for ease in handling.
  • Matching corner and cap for a seamless appearance.
  • Gravity walls can be built up to 4 ft high, including buried course with a 7.1° batter.
  • Walls in excess of 50 ft high have been built with Diamond Pro when combined with geosynthetic reinforcement.
  • Minimum outside radius, measured from the top course to the front of the units: 4 ft.
  • Minimum inside radius, measured on the base course to the front of the units: 6 ft.

*All colors and/or products may not be available in all areas. Please inquire for availability and special order options.

Colors

Buff
Gray
Harvest Blend
Oxford Charcoal
Sheffield Blend
  • * Required

Technical Information
Specs
Technical Information
Filter
Sort

Cut Sheet

Diamond Pro Straight Face – NFD East – Cut Sheet
Download File
Filter
Sort

Estimating Charts

Material Estimating Charts | Diamond Series Walls
Download File
Geosynthetic Estimating Charts | Diamond Pro Walls
Download File
Specs
Anchor Diamond Pro Straight Face Block
Diamond Pro® Straight Face
8 x 18 x 12
XL Cap sm
Diamond Pro® Cap
3 x 18/12 x 13
Anchor Diamond Pro Straight Face Block
Diamond Pro® Corner
8 x 18 x 9
U Start Base Block®
3 1/2 x 18 1/2 x 12
Note: U Start Base Block actual coverage length is 16 11/16"
Note: U Start Base Block actual coverage length is 16 11⁄16"

Diamond Pro® Product Video

Diamond Pro® - English Version

Diamond Pro® - Spanish Version
