Highland Stone®

Scroll to Explore
Highland Stone®

The Highland Stone® retaining wall features the original rear-lip locator for fast, accurate installation. The six-inch system allows for a wide range of design possibilities for your outdoor hardscape. Highland Stone® Freestanding Wall complements the retaining wall, offering almost endless capabilities.

Features & Benefits:

  • Can be used to create straight or curved walls.
  • Rear-lip block makes installation fast and accurate.
  • Freestanding walls can be built up to 3 ft high, including buried course, but excluding the cap.
  • Gravity walls can be built up to 4 ft, 6 in high, including buried course.
  • Taller walls can be built using geosynthetic reinforcement when designed by a qualified engineer.
  • Minimum outside radius, measured on the top course to the front of the units: 4 ft.
  • Minimum inside radius, measured on the base course to the front of the units: 8 ft.

*Swatches represent color only, not surface texture, dimension and or shape.

*All colors and/or products may not be available in all areas. Please inquire for availability and special order options.

Colors

Cotswold Mist
Harvest Blend
Oxford Charcoal
Sheffield Blend
  • * Required

Specs
Technical Information
Specs
Highland Stone® Retaining Wall
6 x 6 x 12
6 x 12 x 12
Highland Stone® Retaining Wall
6 x 18 x 12
Highland Stone® Freestanding Wall
6 x 6 x 9
6 x 12 x 9
Highland Stone® Freestanding Wall
6 x 18/16 x 9
Highland Stone® Large Step
6 x 16 x 12
Highland Stone® Cap
3 x 18/12 x 13
Highland Stone® Column/Corner
6 x 18 x 9
U Start Base Block
3 1/2 x 18 7/16 x 12
*Note: U Start Base Block actual coverage length is 16 11/16.
Sold Separately
Technical Information
Filter
Sort

Cut Sheet

Highland Stone – NFD East – Cut Sheet
Filter
Sort

Estimating Charts

Geosynthetic Estimating Charts | Diamond | Highland | Sterling Wall
Material Estimating Charts | Highland Stone Wall
Material Estimating Charts | Base Course for Walls
