Highland Stone®

The Highland Stone® retaining wall features the original rear-lip locator for fast, accurate installation. The six-inch system allows for a wide range of design possibilities for your outdoor hardscape. Highland Stone® Freestanding Wall complements the retaining wall, offering almost endless capabilities.

Features & Benefits:

  • Can be used to create straight or curved walls.
  • Rear-lip block makes installation fast and accurate.
  • Freestanding walls can be built up to 3 ft high, including buried course, but excluding the cap.
  • Gravity walls can be built up to 4 ft, 6 in high, including buried course.
  • Taller walls can be built using geosynthetic reinforcement when designed by a qualified engineer.
  • Minimum outside radius, measured on the top course to the front of the units: 4 ft.
  • Minimum inside radius, measured on the base course to the front of the units: 8 ft.

*Swatches represent color only, not surface texture, dimension and or shape.

*All colors and/or products may not be available in all areas. Please inquire for availability and special order options.

Colors

Highland Wall Cotswold Mist Swatch
Cotswold Mist
Highland Wall Harvest Blend Swatch
Harvest Blend
Highland Stone Oxford Charcoal Swatch
Oxford Charcoal
Highland Wall Sheffield Blend Swatch
Sheffield Blend
  • * Required

Specs
Technical Information
Specs
Highland Stone Retaining Wall 2pc
Highland Stone® Retaining Wall
6 x 6 x 12
6 x 12 x 12
Highland Stone Freestanding Wall 18in
Highland Stone® Retaining Wall
6 x 18 x 12
Highland Stone FSW SM MD
Highland Stone® Freestanding Wall
6 x 6 x 9
6 x 12 x 9
Highland Stone Retaining Wall 18in
Highland Stone® Freestanding Wall
6 x 18/16 x 9
Highland Stone Large Step
Highland Stone® Large Step
6 x 16 x 12
GMS MidSouth Highland Stone Cap
Highland Stone® Cap
3 x 18/12 x 13
Highland stone Column Corner
Highland Stone® Column/Corner
6 x 18 x 9
U Start Base Block
3 1/2 x 18 7/16 x 12
*Note: U Start Base Block actual coverage length is 16 11/16.
Sold Separately
Technical Information
Filter
Sort

Cut Sheet

Highland Stone – NFD East – Cut Sheet
Download File
Filter
Sort

Estimating Charts

Geosynthetic Estimating Charts | Diamond | Highland | Sterling Wall
Download File
Material Estimating Charts | Highland Stone Wall
Download File
Material Estimating Charts | Base Course for Walls
Download File
